1973 Jeep CJ-5

FREE VIDEO: 4x4 Off Roads Buyers Guide In this video series - the 4x4 Off Roads Buyers Guide you will discover how to select your 4x4, how to evaluate off roading trucks and SUVs and how to find them on eBay - and do it all with confidence!

Major Modifications:

ENGINE

TYPE …………………………………………………………………… FORD 289 V-8
ASPIRATION …………………………………………… MOTORCRAFT 2 BARREL

DRIVETRAIN

TRANSMISSION …………………………………………………………...…...… T-14
TRANSFER CASE ...………………………………………………………… DANA 20


SUSPENSION

LEAF SPRING………………… RUBICON EXPRESS 4.5” EXTREME DUTY (YJ)
SHACKLES …………………………………………………... CURRIE GREASABLE
SHOCKS.……………………………………….………………. TRAIL MASTER SSV

LIFT

BODY …………………………………………………………………………… 2 INCH
SPRING ………………………………………………………………………. 4.5 INCH
SHACKLE ……………………………………………………………………. 1.5 INCH

AXLES/DIFFERENTIALS

F/R…..………... DANA 44 (’75 SCOUT) / YUKON SPOOLS / YUKON 30 SPLINE CROMOLY SHAFTS
RING-AND-PINION ……………………………………………………YUKON 5.13:1

WHEELS AND_TIRES

37X12.5X15 GOODYEAR MT/R ON 15X10 ALLIED ROCKATHON BEADLOCKS

SPECIAL_FEATURES

· ATLAS 9500LB WINCH
· WMS HEAVY DUTY DIFFERENTIAL COVERS
· HEI BILLET DISTRIBUTOR
· CUSTOM FABRICATED LEAF SPRING HANGERS
· K&N FILTERCHARGER
· AGR ROCK RAM
· EXTENDED BRAIDED STAINLESS STEEL FRONT BRAKE LINES
· CUSTOM MADE FRONT AND REAR BUMPERS
· REAR CV DRIVESHAFT
· EXTENDED AXLE AND T-CASE BREATHER TUBES
· ALUMINUM DIAMOND PLATE TALL CORNERS
· 3/16 STEEL ROCKER GUARDS TIED INTO BODY MOUNTS
· CUSTOM GM DELCO/REMY 1 WIRE ALTINATOR WITH SELF EXCITER
· REENFORCED AND BOXED F/R FRAME SECTION
· WARRIOR PRODUCTS STEERING BOX BRACE
· WARRIOR PRODUCTS REAR LEAF SPRING PERCHES (for correct pinion angle)
· HERCULINED INSIDE TUB
· FRONT SHOCKS RELOCATED TO AXLE TUBE USING WARRIOR PRODUCTS LOWER MOUNTS AND WAGONEER UPPER MOUNTS
· CENTERFORCE II CLUTCH
· 4 WHEEL DISC BRAKES
· TUFFY SERIES II SECURITY CONSOLE
· BESTOP TRAILMAX SEATS ON CUSTOM FABRICATED BRACKETS
· CUSTOM EXHAUST, 2 INTO 1 FLOWMASTER 50 SERIES
· WHEELS AND TIRES BALANCED WITH DYNA BEADS
· CLEARANCED FENDERS AND WHEEL WELLS
· 1 TON TIE ROD AND DRAG LINK
· ROLL CAGE 1.75 X .25 WALL DOM

I go wheeling in the Eastern and Central U.S., North & South Carolina, Tennessee, Kentucky, Oklahoma.

I enjoy the rocks.

Brian
